Wall Mounted Water Flow Meter Ultrasonic Doppler Type Portable 12VDC
1 piece
MOQ
Negotiable
Price
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: china
Brand Name: vacorda
Certification: CE/TUV/ISO9001/SGS
Model Number: HKD
High Light:

Wall Mounted Water Flow Meter 12VDC

,

Ultrasonic Doppler Type Water Flow Meter

,

12VDC Ultrasonic Flow Meter

Payment & Shipping Terms
Packaging Details: wooden box
Delivery Time: 15 working day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 400 pieces/month
Specifications
Medium: Flow
Protection Class: IP68
Flow Range: 0.03m/s-5.00m/s
Accuracy: 1mm/s
Water Depth: 0.05m~10.00m
Remprerature Range: 0~60℃
Power Supply: 12VDC
Signal Output: RS485,RS232
Product Description

12VDC Portable Wall Mounted Water Flowmete Ultrasonic Doppler Type Flow Meter Price



Ultrasonic liquid level gauge is a kind of liquid level instrument that uses the ultrasonic principle to measure liquid level. How does the ultrasonic liquid level gauge work? What is the principle of ultrasonic level gauge?

The working principle of ultrasonic liquid level gauge is to transmit energy wave through ⼀ devices that can transmit energy wave (⼀ generally pulse signal). The energy wave is reflected by obstacles, and the reflected signal is received by ⼀ receiving devices.
The change of liquid (material) level is determined according to the time difference of measuring the movement process of energy wave. The microwave signal is processed by the electric device and finally transformed into the electrical signal related to the liquid level.
The secondary probe transmits ultrasonic pulse signal to the measured medium meter. The ultrasonic wave is reflected after encountering the measured medium (obstacle) during transmission, and the reflected ultrasonic signal is detected by the electric module.
Through special software to process, analyze the time difference between transmitting ultrasonic wave and echo. Combined with the propagation speed of ultrasonic wave, the propagation distance of ultrasonic wave can be accurately calculated, and the inlet can reflect the situation of liquid level.

Wall Mounted Water Flow Meter Ultrasonic Doppler Type Portable 12VDC 0Wall Mounted Water Flow Meter Ultrasonic Doppler Type Portable 12VDC 1

Wall Mounted Water Flow Meter Ultrasonic Doppler Type Portable 12VDC 2



Ultrasonic Flow Meter

Features of ultrasonic level gauge
Multi pulse low-voltage multi-point transmitting circuit, double balance noise suppression multi-point receiving circuit (qf-9000 Series): improve the reliability of the instrument, solve the problem of inaccurate measurement of uneven material level, and strengthen the anti-interference energy. It can stably make dynamic power adjustment, gain control and temperature compensation near the transmitting tower of the substation.
Advanced detection technology and rich software functions adapt to various complex environments.
Adopt new waveform calculation technology to improve the measurement accuracy of the instrument.
It has the function of suppressing disturbing echo to ensure the authenticity of measured data.
16 bit D / a conversion to improve the accuracy and resolution of current output.
The sensor is made of Teflon, which can be used in various corrosive occasions.
Various output forms: programmable relay output, high precision 4-20mA current output, RS-485 digital communication output, split ultrasonic liquid level probe



Product Parameters

(1)Flow rate range 0.01 ~ ±32 m/s
(2)Flow range 0.1 to 99999999 m3/h caliber (mm)
(3)Diameter range DN32-10000mm (selected sensor when order)
(4)Accuracy Linearity is better than 0.5%, repeatability accuracy is better than 0.2%, up to 40 picosecond time difference measurement resolution, so that the measurement accuracy reaches + 1%.
(5)Pulse output Isolated programmable OCT output
(6)Working voltage Isolation of DC12-36V or AC180-250V
(7)Shell material Cast aluminum /ABS (host), sensor (ABS).
(8)Installation Wall hanging (main engine), magnetic sucker and hoop (sensor).
(9)Protection grade IP65 (host), IP65 (sensor) (customizable higher protection level).
Detailed Images

Wall Mounted Water Flow Meter Ultrasonic Doppler Type Portable 12VDC 0Wall Mounted Water Flow Meter Ultrasonic Doppler Type Portable 12VDC 5

Integrated installation principle of ultrasonic level gauge
1.The distance from the emitting surface of the sensor to the lowest liquid level should be less than the measuring range of the selected instrument.
2.The distance from the emitting surface of the sensor to the highest liquid level should be greater than the blind zone of the selection and purchase of the instrument.
3.The emitting surface of the sensor should be parallel to the liquid surface.
4.The installation position of the sensor should avoid the fluctuation of the liquid level as much as possible, such as the water inlet and outlet.
5.If the pool or tank wall is not smooth, the instrument should keep the pool or tank wall above 0.3m.
6.If the distance from the transmitter surface of the sensor to the highest liquid level is less than the blind zone of the selected instrument, a telescopic tube should be installed, the diameter of which is greater than 120 mm, the length is 0.35m ≤ 0.50m, the vertical installation, the inner wall is smooth, and the inner hole of the tank should be Greater than the inner diameter of the extension tube. Or the pipe can be directly connected to the bottom of the tank, the pipe diameter is greater than 80 mm, and the hole at the bottom of the pipe can easily flow into liquid.
